Fumes Don’t Stand a Chance
Lincoln Electric’s X-Tractor 1 Fume gun is a high vacuum extraction system designed for the removal and filtration of welding fume. The 1GC is a great choice for fume removal on the light-duty welding applications typically found in shops or companies with a small number of welding stations. This compact size and light weight makes the unit easy to move to where it’s needed.
- Economical fume movement and ventilation option
- Easily disassemble the unit for cleaning and maintenance
- Maximum extraction distance up to 33 ft. (10 m)
- Quiet operation
- 230V/1/50/60 – 9A Input current
Features
- Simple to Configure – Uses a single fume extraction welding gun or suction nozzle attachment
- Filter Cleaning System – Unique rotary air jet system allows the polyester filter to be cleaned using compressed air without removing it from the X-Tractor 1 Fume Gun
- Automatic Start/Stop Sensor – Provides extraction only when needed, extends motor life, and reduces energy consumption
- Wide Variety of Extraction Nozzles Available – Easily adapt the X-Tractor 1 Fume Gun for many different welding applications
- Low Noise Operation – 74 dBA @ 3.3 ft. (1 m)
- 1-Year Warranty
Included with Product
Base Unit (K652-1)
-
Adapter for 1-3/4 in. (45 mm) hose
-
16 ft. (5 m) long x 1-3/4 in. (45 mm) diameter flexible hose
-
2 spare sets of carbon brushes for motors
-
Filter cartridge
-
12 ft. (3.6 m) power cord
